China Moneypro Drone Signal Detection And Simulation Devices SMA DJS10-5000

The T30 is a lightweight, portable short-range defense continuous-wave radar system. Utilizing DBF digital beamforming and simultaneous multi-beam technology, it can detect target motion speeds from 1 to 300m/s, with pitch angles ranging from-5 to 60 degrees. The radar achieves angular accuracy of 0.3 degrees and distance resolution of 5 meters, featuring data refresh rates of 1/2/3 seconds. It supports stable tracking of over 500 target groups simultaneously. Its scanning range covers areas with altitudes ≥4500m and radii ≥30km. The portable rotating platform consumes ≤450W, while the radar unit weighs less than 30kg. For the smallest DJI mini series UAVs, it provides detection ranges ≥6.5km, and for DJI mavic3 Pro models, ≥10km. With a maximum transmission power of ≤40W, it ensures exceptional operator safety and urban environmental compatibility. On battlefields, its minimal transmission power significantly reduces interception probability, enhancing operational survivability. Among low-power anti-unmanned/loitering radar systems, its technical performance stands unmatched.

China Moneypro MMB series is a portable passive electro-optical radar designed for all-weather 360° panoramic monitoring. Equipped with industry-leading 12μm uncooled infrared detectors (384×288 or 640×512 optional), the system integrates advanced infrared imaging algorithms to deliver long-range and high-clarity imaging. Compact, lightweight (5.1 kg), and highly mobile, it supports tripod, magnetic base, and vehicle-mounted deployment for patrol operations. The system provides full 360° panoramic video surveillance, completing one rotation in ~2 seconds, while simultaneously tracking up to 128 targets including people, vehicles, ships, drones, and crawling intruders. Its intelligent detection algorithms fuse AIS and GIS information for precise target identification and clutter suppression, ensuring reliable intrusion alerts in real time.
