Core Technology
- 5km Effective Range: Covers large protected areas against commercial and professional drones
- Multi-System Compatibility: Simultaneously spoofs GPS (1575.42MHz), GLONASS (1602.0MHz), BeiDou (1575.42MHz), and Galileo (1561.098MHz)
- Stealth Operation: ≤10dBm power maintains effectiveness while minimizing detection risk
- Rugged Design: IP66-rated enclosure withstands extreme temperatures (-40°C to 70°C)
- Plug-and-Play: Simple AC 220V power requirement for immediate deployment
Technical Specifications
| Parameter | Specification |
|---|---|
| Effective Range | 5,000 meters |
| Frequency Bands | GPS L1, GLONASS G1, BeiDou E1, Galileo B1 |
| Power Requirement | AC 220V |
| Dimensions | 447×375×171mm |
| Weight | 12kg |
| Environmental Rating | IP66, -40°C to 70°C |
Operation Principle
- Deploys regenerative navigation signals to override drone GNSS receivers
- Forces drones to follow false coordinates or enter failsafe mode
- Prevents unauthorized drones from reaching protected areas
- Effective against all commercial drones relying on satellite navigation
Competitive Advantages
- Proven Effectiveness: Field-tested against common commercial drone models
- Compact Design: Smaller than comparable systems (44.7×37.5×17.1cm)
- Low Power Consumption: Energy-efficient operation
- China Manufacturing: Cost-effective solution without quality compromise
Compliance & Standards
- Meets international electromagnetic emission standards
- Designed for lawful defense applications
- Compatible with drone defense regulation frameworks
