Technical Features & Specifications
-
Advanced BeiDou Performance
-
BDS B1I signal reception
-
88-channel parallel processing
-
Cold start: <35 seconds
-
Hot start: <1 second
-
Reacquisition: <2 seconds
-
Tracking sensitivity: -158 dBm
-
Capture sensitivity: -145 dBm
-
-
Industrial-Grade Design
-
Operating temperature: -40°C to +85°C
-
Storage temperature: -55°C to +105°C
-
Vibration resistance: 4Grms
-
Shock resistance: 1500g
-
IP65 protection rating
-
ESD protection: ±6kV contact discharge
-
-
Precision Performance
-
Horizontal positioning accuracy: 2.5m
-
Velocity accuracy: 0.1m/s
-
Timing accuracy: 30ns
-
Maximum update rate: 5Hz
-
Position dilution of precision (PDOP): <1.5
-
Interface & Integration
Standard Interfaces:
-
UART (3.3V TTL, 5V tolerant)
-
I2C communication
-
SPI interface
-
USB 2.0 connectivity
Customization Options:
-
Protocol adaptation and development
-
Data output format customization
-
NMEA message configuration
-
Baud rate adjustment (4800-460800 bps)
-
Power management settings
-
Private protocol support
-
Hardware interface modification
Application Areas
Industrial Computing:
-
Industrial PC integration
-
Embedded system applications
-
Factory automation
-
Machine control systems
-
Process monitoring equipment
Industrial Control:
-
Automated guided vehicles (AGVs)
-
Robotic positioning systems
-
Crane and hoist monitoring
-
Conveyor system tracking
-
Equipment localization
DIY & Custom Projects:
-
Drone navigation systems
-
Vehicle tracking devices
-
Research and development
-
Educational projects
-
Prototype development
-
IoT applications
Technical Support & Services
Development Support:
-
Comprehensive technical documentation
-
Software development kit
-
Protocol specification documents
-
Hardware design guidelines
-
Application examples
-
Integration tutorials
Customization Services:
-
Interface protocol adaptation
-
Firmware customization
-
Hardware modification
-
Performance optimization
-
Application-specific solutions
-
Technical consultation
Quality Assurance:
-
CE certification
-
RoHS compliance
-
ISO 9001 quality management
-
24-month warranty period
-
Professional technical support
-
Reliable supply chain
Product Advantages
Reliability:
-
Stable signal reception
-
Consistent performance
-
Long-term durability
-
Industrial-grade components
-
Quality manufacturing
Flexibility:
-
Multiple interface options
-
Customizable protocols
-
Adaptable to various applications
-
Scalable solutions
-
Easy integration
Cost-Effectiveness:
-
Competitive pricing
-
Low power consumption
-
Reduced development time
-
Minimal maintenance required
-
Long service life
Why Choose Moneypro MQD-50DN?
The Moneypro MQD-50DN offers a perfect combination of precision, reliability, and flexibility for industrial and custom applications. With its dedicated BeiDou system support, industrial-grade construction, and comprehensive customization options, this module provides an ideal positioning solution for various requirements. Our professional technical team ensures smooth integration and offers continuous support throughout your project development.
