Key Features & Technical Specifications
-
Dual-System Superior Performance
-
Simultaneous BDS B1I and GPS L1C/A signal reception
-
132-channel advanced processing architecture
-
Cold start: <30 seconds
-
Hot start: <1 second
-
Reacquisition: <2 seconds
-
Tracking sensitivity: -160 dBm
-
-
Industrial-Grade Reliability
-
Operating temperature: -40°C to +85°C
-
Storage temperature: -55°C to +105°C
-
Vibration resistance: 5Grms
-
Shock resistance: 2000g
-
IP67 protection rating
-
ESD protection: ±8kV contact discharge
-
-
Precision Performance Metrics
-
Horizontal positioning accuracy: 2.0m
-
Velocity accuracy: 0.1m/s
-
Timing accuracy: 20ns
-
Maximum update rate: 10Hz
-
Position dilution of precision (PDOP): <1
-
Interface & Customization Options
Standard Interfaces:
-
UART (3.3V TTL)
-
I2C
-
SPI
-
USB 2.0
Customization Capabilities:
-
Protocol adaptation
-
Data output rate configuration
-
NMEA message selection
-
Baud rate adjustment (4800-921600 bps)
-
Power mode configuration
-
Private protocol development
Application Scenarios
Industrial Systems:
-
Industrial computer integration
-
Programmable logic controller (PLC) systems
-
Industrial automation equipment
-
Smart manufacturing systems
-
Quality control instruments
Control Systems:
-
Automated guided vehicles (AGVs)
-
Robotic positioning systems
-
Crane monitoring
-
Precision agriculture
-
Construction machinery
DIY & Custom Projects:
-
Drone navigation systems
-
Vehicle tracking devices
-
Scientific research equipment
-
Educational demonstration platforms
-
Prototype development
Technical Support & Services
Development Support:
-
Comprehensive technical documentation
-
Software development kit (SDK)
-
Protocol specification manual
-
Hardware design guide
-
Application notes
Customization Services:
-
Interface protocol customization
-
Firmware modification
-
Hardware adaptation
-
Performance optimization
-
Application-specific solutions
Quality Assurance:
-
CE certification
-
RoHS compliance
-
ISO 9001 quality management
-
24-month warranty
-
Professional technical support
Why Choose Moneypro MQD-50DU?
The Moneypro MQD-50DU offers unparalleled flexibility and reliability for both industrial applications and custom projects. With its dual-system compatibility, industrial-grade construction, and extensive customization options, this module provides a perfect balance of performance and versatility. Our professional technical team ensures seamless integration and provides comprehensive support throughout your project lifecycle, from initial design to final implementation.
