Transmission Distance
- 50KM
Product Feature
- Support medium and long-distance transmission
- Support networking
- Support frequency hopping
Product Parameter
| System parameter | Technical index |
|---|---|
| Equipment type | T900 – 35A – SMA |
| Working frequency | 902 – 928MHz |
| Modulation mode | FSK |
| Spread spectrum | FHSS |
| Output power | 35dBm (3W) |
| Transmission distance | 50KM (LOS) |
| Working mode | P2P, P2MP, Mesh with a center |
| Transmission rate | 57.6Kbps – 276.4Kbps |
| Data interface | GH1.25 – 4PIN |
| Configuration interface | USB |
| Antenna interface | SMA – Female |
| Voltage range | DC9 – 32V; Typical: +24V |
| System power consumption | <20W |
| Dimension(L*W*H) | 41*65*13.5mm |
| Weight | 57g |
| Working temperature | -40 – +65°C |
