1. Key Features – Industrial-Grade Performance
- 70kg Max Payload: Carry LiDAR, multispectral sensors, or emergency supplies.
- Extended 60-Minute Flight: 12 m/s cruising speed for large-area mapping/inspections.
- 20–30km Transmission: Dual-link redundancy (4G/5G optional).
2. Technical Specifications
| Category | Details |
|---|---|
| Dimensions | Folded: 860×860×850 mm (portable) / Unfolded: 1,587×1,514×891 mm |
| Weight | 70kg (aircraft) / 140kg max takeoff |
| GNSS | GPS+GLONASS+BeiDou+Galileo (cm-level RTK optional) |
| Wind Resistance | Level 6 (12 m/s) with IP54 dust/water protection |
| Altitude | Operates up to 5,000m for mountainous/offshore missions |
3. Advanced Navigation & Durability
- Multi-Constellation GNSS: Auto-switches between GPS/BeiDou for signal stability.
- -20°C–60°C Operation: Heated batteries for Arctic/oil rig deployments.
- Modular Design: Quick-swap payload bays (thermal, gas detectors, etc.).
4. Applications – Where Moneypro 10 Excels
Energy Sector
- Power line inspections (70kg payload carries HD zoom + LiDAR).
- Offshore wind turbine maintenance (IP54 salt-spray resistance).
Public Safety
- Search & rescue (30km video transmission in wildfires/floods).
Agriculture
- Large-scale fertilizer spraying (1,587mm wheelbase stabilizes tanks).
5. Why Choose Moneypro 10 Over Competitors?
- Higher Payload-Thrust Ratio vs. DJI Matrice 300 (70kg vs. 40kg).
- Faster Deployment: Folds to 0.86m³ for truck/helibox transport.
- Global GNSS: Ideal for Asia (BeiDou) and Europe (Galileo).
