Key Features & Specifications
1. Industry-Leading Payload & Flight Time
✔ 10 kg max payload – Supports LiDAR, high-resolution cameras, large sensors
✔ 70-minute max flight time (optimized battery efficiency for extended missions)
✔ 5000 m max altitude (high-altitude operations in mountainous regions)
2. Long-Range, Secure Transmission
✔ 30 km HD real-time transmission (low-latency, encrypted data link)
✔ Dual-frequency GNSS (GPS+GLONASS+BeiDou+Galileo) for cm-level RTK accuracy
✔ 20 m/s max speed for rapid response in emergency scenarios
3. Rugged & All-Weather Design
✔ IP54 protection (dustproof, splash-resistant)
✔ Level 6 wind resistance (stable in 12 m/s winds)
✔ -20°C to 60°C operating range (arctic to desert-ready)
4. High-Payload Modular System
✔ Quick-release payload mounts for sensors, cameras, or cargo containers
✔ Redundant propulsion system for fail-safe operations
✔ 4 m/s ascent/descent speed (precise maneuverability under heavy loads)
Why Choose the Moneypro 4?
✔ Heaviest payload in its class (10 kg) – Ideal for industrial inspections, medical deliveries, defense
✔ Ultra-long 70-minute endurance – Covers vast areas without frequent landings
✔ 30 km secure transmission – Live HD data streaming for remote command centers
✔ Extreme weather adaptability – Deploys in blizzards, deserts, and high winds
Packaging & Dimensions
- Drone Size (Assembled): 1650 × 1650 × 560 mm
- Wheelbase: 1650 mm
- Aircraft Weight: 18 kg (28 kg max takeoff weight)
- Package Dimensions:
- Fuselage Box: 830 × 750 × 600 mm (26.5 kg)
- Arm Box: 1090 × 440 × 300 mm (12.6 kg)
- Total Shipping Weight: 39.1 kg (modular packaging for easy transport)
Applications
✔ Heavy Cargo Delivery (medical supplies, disaster relief, military logistics)
✔ Oil & Gas Inspections (pipelines, rigs, flare stacks with thermal imaging)
✔ Large-Scale Surveying & Mapping (LiDAR, photogrammetry for mining/construction)
✔ Search & Rescue (long-range payload drops, thermal detection in remote areas)
