Key Features
- High-performance infrared detector: 12 μm uncooled infrared detector or optional cooled MWIR sensor.
- 360° panoramic monitoring: ~2 s per full scan, seamless panoramic video output with no blind spots.
- Multi-target tracking: Tracks up to 128 targets simultaneously, including humans, vehicles, ships, and UAVs.
- Dual-spectrum linkage: Integrates with visible-light cameras for enhanced recognition, zoom, and evidence collection.
- AI detection algorithms: Automatic recognition of targets with AIS/GIS fusion, clutter suppression, and intrusion alerts.
- Off-grid operation: Supports solar-powered deployment and wireless AP transmission in network/power-limited environments.
Technical Specifications
| Model | 1255 | 1275 |
| Detector Type | Uncooled IR | Uncooled IR |
| Resolution | 1280×1024 | 1280×1024 |
| Focal Length | 55 mm | 75 mm |
| Panoramic Resolution | 28792×1024 px | 39200×1024 px |
| Frame Rate | 180°/s | 164°/s |
| Horizontal FOV | 12.7° | 9.4° |
| Elevation FOV | 360° | 360° |
| Tilt Adjustment | −20° ~ +35° | −20° ~ +35° |
| Detection Range (Personnel, 1.7 m) | 1 km | 1.5 km |
| Detection Range (Vehicle, 4 m) | 3 km | 6 km |
| Detection Range (Small Boat, 8 m) | 4 km | 8 km |
| Detection Range (UAV, 450 mm) | 1.5 km | 2 km |
| Dimensions | 382 × 260 × 386 mm | 382 × 260 × 386 mm |
| Weight | 20 kg | 20 kg |
| Power Supply | DC 30V 5A | DC 30V 5A |
| Average Power Consumption | < 35 W | < 35 W |
| Operating Temperature | −40 °C ~ +70 °C | −40 °C ~ +70 °C |
| Protection | IP66 | IP66 |
Applications
- Border and coastal defense monitoring
- Key site and perimeter protection
- Oil & gas pipeline and infrastructure security
- Maritime patrol and small craft monitoring
- UAV intrusion detection in restricted zones
Professional FAQs
Q1: What makes the China Moneypro M12 unique compared to traditional radars?
A1: Unlike conventional radars, the China Moneypro M12 passive infrared detection, making it undetectable, silent, and highly effective for stealth surveillance in sensitive environments.
Q2: How does the dual-spectrum linkage improve detection?
A2: When an intrusion is detected via infrared, the system automatically cues a visible-light camera for zoomed-in observation, image capture, and evidence collection, ensuring multi-spectrum confirmation.
Q3: What is the maximum number of targets it can track?
A3: The system can track up to 128 simultaneous targets including humans, UAVs, vehicles, and ships across an 8 km detection radius.
Q4: Can it operate in harsh field conditions?
A4: Yes. With IP66 protection, an operating temperature range of −40 °C to +70 °C, and multi-layer anti-corrosion design, it is built for coastal, desert, and high-humidity environments.
Q5: Is the China Moneypro M12 suitable for off-grid or remote areas?
A5: Absolutely. It supports solar power supply and wireless AP transmission, enabling deployment in locations without fixed power or network infrastructure.
