Product Features
Default outputs include:
- 3-axis angular velocity
- 3-axis acceleration
- Temperature data
Applications
- Guidance and stabilization systems
- Tunnel surveying and mapping
- Vehicle and ship navigation
- UAV and autonomous driving platforms
- Industrial robotics and precision measurement
- Satellite attitude control systems
- Oil drilling and resource exploration
- Geodetic surveying and geophysics
- Optical and laser measurement systems
Performance Specifications
| Parameter | Specification |
| General | |
| Weight | 55 g |
| Measurement Range | ±400°/s |
| Resolution | 24 bits |
| Startup Time | 3–6 s |
| Sampling Rate | 125–1000 Hz |
| Shock Resistance | 1500 g |
| Power | |
| Supply Voltage | 4.5 V – 5.5 V (typ. 5 V) |
| Power Consumption | 1.2 W (typ.) / 1.5 W (max) |
| Gyroscope Performance | |
| Bias Instability | 0.4°/h |
| Angular Random Walk | 0.17°/√h |
| Nonlinearity (±250°/s) | 25 ppm |
| Bias Temperature Sensitivity | ±30°/h rms |
| Bandwidth (–3 dB) | 262 Hz |
| Environmental | |
| Operating Temperature | –40 °C ~ +85 °C |
| Storage Temperature | –50 °C ~ +90 °C |
| Interface | |
| Data Interface | RS422 |
| Data Latency | 1.6 ms |
| Bit Rate | Up to 921,600 Mbit/s |
Key Benefits
- Ultra-low bias instability (0.4°/h)for high precision navigation
- Compact and lightweight(55 g) for integration into UAVs and robotics
- Fast startup time (≤ 6 s)for rapid deployment
- High resilience with 1500 g shock resistance
- Wide temperature range (–40 °C to +85 °C)for demanding environments
- Fully ITAR-free, ensuring ease of export and global deployment
Q1: What makes China Moneypro MP-IM202 different from other MEMS gyroscopes?
A1: China Moneypro MP-IM202 stands out with its ultra-low bias instability of 0.4°/h, angular random walk of 0.17°/√h, and 24-bit resolution. Combined with a compact weight of only 55 g, it provides navigation-grade performance in a MEMS form factor, making it suitable for aerospace, UAV, robotics, and industrial guidance systems.
Q2: How fast can China Moneypro MP-IM202 be initialized for field operations?
A2: China Moneypro MP-IM202 supports rapid startup within 3–6 seconds, enabling quick deployment in time-sensitive operations such as UAV take-off, tunnel surveying, and autonomous driving systems.
Q3: Is China Moneypro MP-IM202 export-restricted under ITAR?
A3: No. Unlike many high-performance gyroscope modules, China Moneypro MP-IM202 is ITAR-free, making it easy to integrate and export globally without licensing restrictions. This is a key advantage for international customers in defense, aerospace, and industrial sectors.
Q4: What kind of environments can China Moneypro MP-IM202 operate in?
A4: China Moneypro MP-IM202 is designed for harsh environments, with an operating range of –40 °C to +85 °C and shock resistance up to 1500 g. This durability ensures reliable performance in mining, drilling, robotics, and geophysical exploration.
Q5: What are the typical applications of China Moneypro MP-IM202?
A5: China Moneypro MP-IM202 is widely used in:
- UAVs and autonomous driving platformsfor navigation stability
- Industrial roboticsfor precision angle measurements
- Geodetic and tunnel surveyingfor accurate mapping
- Oil and gas drilling systemsfor orientation control
- Satellite attitude and antenna stabilization
