Key Features
- Automatic target distance calculation and real-time reticle adjustment via integrated LRF module.
- Equipped with 3rd-gen 12μm / 640×512 (50Hz) infrared detector for smooth, high-resolution imaging.
- Detects and identifies human targets up to 700 meters.
- Battery replacement without shutdown for 24/7 operations.
- Lightweight magnesium alloy shell with IP67 protection, designed for complex environments.
- Intuitive single-scrollwheel interface for effortless control.
- Shock resistance up to 1200g/0.3ms, capable of operating in extreme climates.
- Directional guidance indicators, photo/video capture, stores up to 10,000 images or 12 hrs of video.
- Supports Wi-Fi transmission and remote command.
- Intelligent reticle adjustment for increased first-round hit probability.
- Multiple reticle options (range & mil-dot) to optimize accuracy.
- Adaptable to a wide range of weapon platforms.
- Modular design for rapid deployment.
Technical Specifications
IR Parameters
- Resolution: 640×512
- Pixel Pitch: 12μm
- Frame Rate: 50Hz
- OLED: 1024×768
Power Supply
- Battery: External 1×18650 / Internal 2×18500
- Operating Time: 12h
Physical Parameters
- Weight: ≤750g
- Dimensions: ≤245mm × 95mm × 95mm
Optical Parameters
- Focal Length: 45mm F1.1
- FOV: 9.7° × 7.8°
- Diopter Adjustment: -4D ~ +2D
- Exit Pupil Distance: ≥35mm
Laser Module
- Wavelength: 905nm
- Range: 50–2000m
- Accuracy: ±2m
- Display: 0.96″ OLED
- Removable: Yes
Environmental Requirements
- Protection: IP67
- Operating Temperature: -40℃ ~ +55℃
- Reliability: 1200g/0.3ms
Functional Parameters
- Display Modes: White Hot, Black Hot, Red Hot, Green Hot, Lava, Rainbow, Outline
- Digital Zoom: 1–4×
- Digital Compass: Azimuth, Pitch, Roll angle
- Memory: 128GB
- Intelligent Target Recognition: Personnel, vehicles, drones, etc.
- Reticle: Multiple range and mil-dot
- Custom Reticle: Supports offline upgrades
- Picture-in-Picture: Yes
- One-Click Zeroing: Yes
- Ballistic Calculation: Yes
- Wi-Fi: Yes
Interfaces
- Electrical: Type-C / RS232 / PAL
- Mechanical: Standard Picatinny Rail
Effective Range
- Personnel Recognition (IR):up to 0.75 km
- Personnel Detection (IR):up to 1.8 km
- Vehicle Recognition (IR):up to 1.5 km
- Vehicle Detection (IR):up to 3.75 km
FAQ
Q1: How accurate is the China Moneypro MPS645-L’s laser ranging system?
A1: China Moneypro MPS645-L offers laser ranging with ±2m accuracy across distances from 50m up to 2000m, ensuring reliable target data for both long- and short-range engagements.
Q2: Can the device be used continuously in harsh environments?
A2: Yes. With IP67 protection and shock resistance of 1200g/0.3ms, it operates flawlessly in extreme cold, heat, high-altitude plateaus, and humid rainforest conditions.
Q3: How does Wi-Fi integration improve mission performance?
A3: Wi-Fi enables real-time image streaming and data transfer to command centers or mobile devices, ensuring tactical teams have synchronized situational awareness during operations.
Q4: What makes the ballistic calculation system unique?
A4: The integrated ballistic computer automatically calculates trajectory adjustments based on laser range data, optimizing reticle alignment and significantly increasing first-round hit probability.
Q5: How does China Moneypro MPS645-L compare with conventional thermal sights?
A5: Unlike conventional models, the China Moneypro MPS645-L combines thermal + laser + Wi-Fi + ballistic computation in one compact platform, making it one of the most advanced multi-role thermal gun sights available globally.
