Key Features & Capabilities
- All-Weather, Day/Night Operation: Effective in rain, fog, and dust with low false alarm rates.
- Multi-Target Tracking: Simultaneous tracking of >200 moving targets, including crawling personnel, armed soldiers, vehicles, tanks, and boats.
- Detection Range:
- Personnel (1.5 m² RCS): ≥18 km
- Light Vehicles (10 m² RCS): ≥25 km
- Tanks / Heavy Vehicles (30 m² RCS): ≥35–40 km
- Low-flying UAVs (0.01–0.05 m² RCS): ≥8–12 km
- Accuracy:
- Range accuracy: ≤5 m
- Azimuth accuracy: ≤0.3°
- Radial velocity accuracy: ≤0.2 m/s
- Target Classification: AI-enhanced algorithms distinguish crawling individuals vs. walking soldiers, and light vehicles vs. heavy armor.
- ECCM Performance: Adaptive frequency agility, sidelobe cancellation >60 dB, and resistance to co-channel jamming with >90 dB J/S ratio tolerance.
- Deployment: Lightweight (system weight <30 kg in man-portable configuration), setup time <10 minutes.
- Power Supply: Vehicle DC, battery, or portable generator; continuous operation >24 h.
Applications
- Battlefield Reconnaissance & Monitoring: Detection of soldiers, vehicles, and UAVs; battle damage assessment; mission support for artillery and UAV strike coordination.
- Homeland Security & Counter-Terrorism: Protection of airports, dams, power stations, pipelines, ports, and major events with 24/7 surveillance and alarm functions.
- Border & Coastal Defense: Persistent surveillance of personnel, vehicle movement, and maritime traffic; deployable on UAVs, ships, or land-based stations.
Comparison with Leading International Systems
| Parameter | Elta EL/M-2112 (Israel) | Thales BOR-A 550 (France) | China MoneyPro UAV – GSR |
| Personnel Detection Range | ~10–12 km | ~15 km | ≥18 km |
| Vehicle Detection Range | ~20 km | ~24 km | ≥25 km (light), ≥35–40 km (heavy) |
| UAV Detection (small RCS 0.01 m²) | ~5–6 km | ~7–8 km | ≥8–12 km |
| Simultaneous Targets | ~100–120 | ~150 | >200 |
| Range Accuracy | 10 m | 7 m | ≤5 m |
| ECCM Performance | Frequency agility | Frequency agility + sidelobe cancelation | Adaptive ECCM, >90 dB J/S ratio |
| Weight (portable set) | ~35–40 kg | ~32 kg | <30 kg |
| Deployment Time | ~15–20 min | ~15 min | <10 min |
| Integration | Vehicle & fixed | Vehicle & tripod | Vehicle, tripod, UAV pod, man-portable |
Why Choose China MoneyPro – GSR Ground Surveillance Radar?
- Superior Range & Accuracy: Detects personnel beyond 18 km and vehicles up to 40 km, outperforming most international peers.
- AI-Powered Target Classification: Enhanced identification of target type and movement pattern.
- Compact & Rapidly Deployable: <30 kg modular design with setup under 10 minutes.
- Versatility: Operable on vehicles, UAVs, ground stations, and naval platforms.
- Future-Proof: Open architecture for integration with C4ISR networks, UAV strike systems, and counter-drone solutions.
The China MoneyPro Ground Surveillance Radar sets a new benchmark for battlefield surveillance by combining extended detection range, superior anti-jamming, multi-platform adaptability, and AI-enhanced classification. It is the ideal solution for clients seeking world-class ISR (Intelligence, Surveillance & Reconnaissance) capabilities for defense, homeland security, and border protection.
