Flight Control Configuration
| Version | / |
| Flight Controller | Industrial flight control |
| GPS | / |
| Drone Frame | √ |
| VTOL Motor | 4pcs |
| VTOL ESC | 4pcs |
| VTOL Propeller | 2Pairs |
| RC&Ground Station | 1x FT24 14Channels RC |
| Video Transmitter | / |
| Battery | / |
| Battery Charger | / |
| Carrying Case | √ |
| Assembling, tuning and flight test service | √ |
Specification
| Model No. | HVT460 |
| Type | Hybrid VTOL Fixed Wing |
| Color | White |
| Wingspan | 4600mm |
| Length | 2360mm |
| Height | 1045mm |
| Material | Glass fiber + carbon fiber composite material |
| MTOW | 59kg |
| Max Load | 18kg (task+ petrol load) |
| Suggested Load | 8kg |
| Flight Time | 8~10 hours with 5kg payload, 6~8 hours with 8kg payload |
| Economic-Cruising Speed | 100km/h |
| Max Flight Altitude | 4200m |
| Max Wind Resistance | Level 7 |
| Fuel Tank Capacity | 18L |
| Battery (Recommended) | 4* 14S 5200mAh, 1*6S 12000mAh |
| Working Temperature | -10℃~60℃ |
| IP Grade | IP45 |
