Unmatched Performance for Commercial UAV Applications
• 15 kg max payload – Supports multiple professional payload configurations
• 3-hour continuous operation – Extended mission capability
• 80 km long-range transmission – Reliable data link for remote operations
• IP54 protection – Built to withstand harsh environmental conditions
• Multi-GNSS positioning (GPS+GLONASS+BeiDou+Galileo) – Exceptional navigation accuracy
Detailed Technical Specifications
Dimensions & Weight:
| Specification | Value |
|---|---|
| Body Length | 2580 mm |
| Wingspan | 4800 mm |
| Aircraft Weight | 20 kg |
| Max Takeoff Weight | 65 kg |
Performance Metrics:
| Specification | Value |
|---|---|
| Max Flight Time | 180 min |
| Cruising Speed | 26 m/s (94 km/h) |
| Max Speed | 40 m/s (144 km/h) |
| Max Ascent Speed | 3 m/s |
| Max Descent Speed | 2.5 m/s |
| Service Ceiling | 4500 m |
Communication & Environment:
| Specification | Value |
|---|---|
| Transmission Range | 80 km |
| GNSS System | Quad-constellation |
| Wind Resistance | Level 7 |
| Operating Temp Range | -20°C to 60°C |
Designed for Commercial-Grade Performance
Industrial Inspection
✔ Power line monitoring
✔ Pipeline surveys
✔ Wind turbine inspections
Precision Agriculture
✔ Crop health monitoring
✔ Precision spraying
✔ Field mapping
Public Safety & Security
✔ Search and rescue operations
✔ Border patrol
✔ Emergency response
Scientific Research
✔ Atmospheric sampling
✔ Wildlife monitoring
✔ Geological surveys
Why Moneypro 5 Outperforms Competitors
| Feature | Moneypro 5 | Typical Competitor |
|---|---|---|
| Payload Capacity | 15 kg | 8-10 kg |
| Flight Duration | 180 min | 120-150 min |
| Max Speed | 144 km/h | 100-120 km/h |
| GNSS Systems | 4 constellations | 2-3 constellations |
| Transmission Range | 80 km | 40-50 km |
Frequently Asked Questions
Q: What professional payloads can the Moneypro 5 support?
A: Compatible with high-resolution cameras (up to 61MP), multispectral/hyperspectral sensors, LiDAR systems up to 15kg, and specialized scientific instruments.
Q: What’s the typical delivery time for orders?
A: Standard orders ship within 5-7 business days from our Shenzhen facility. Bulk orders may qualify for expedited shipping.
Q: Can the drone operate in rainy conditions?
A: With its IP54 rating, the Moneypro 5 can operate in light rain and dusty environments, though we recommend avoiding heavy precipitation.
