Home » Unmanned System Products » MYD-SwiftLink 2W(MINI)
MYD-SwiftLink 2W
Back to products
MYD-SwiftLink 2W(dual-band)

MYD-SwiftLink 2W(MINI)

The MYD-SwiftLink 2W(MINI) is a compact, high-performance wireless module delivering long-range connectivity for IoT and M2M applications.
Despite its small footprint, it offers a powerful 2W transmit power and excellent receiver sensitivity, ensuring reliable communication up to 2km line-of-sight.
The module supports AES-128 encryption for secure data transmission and features low power consumption for battery-powered devices.
It offers flexible integration through a UART interface with AT command support and includes an SMA antenna connector.
With a wide operating temperature range (-40°C to +85°C), this miniature yet robust module is ideal for industrial monitoring, smart agriculture, security systems, and space-constrained IoT deployments.
Category:
Description

Transmission Distance

  • 30KM+

Product Feature

  • Support cluster work
  • Support automatic frequency selection
  • Support repeater function

Product Parameter

System parameter Technical index
Equipment type S1400 – P33 – MINI S5700 – P30 – MINI
Working frequency 1350~1470MHz（1.4G） 5655 – 5775MHz（5.7G）
Radio frequency channel 2T2R 2T2R
Output power 33dBm (2W) 30dBm (1W)
Transmission distance 30KM+ (LOS) 10KM+ (LOS)
Channel bandwidth 10MHz/20MHz 10MHz&20MHz
Modulation mode QPSK, 16QAM QPSK, 16QAM
Maximum rate 16.8Mbps@10MHz (P2P); 26.4Mbps@20MHz (P2MP) 16.8Mbps@10MHz; 23.9Mbps@20MHz
Communication encryption AES256 AES256
Transmission delay ≤10ms ≤10ms
Radio frequency interface SMA*2 SMA*2
Device interface Ethernet*1; TTL/RS232/SBUS*2 Ethernet*1; TTL/RS232/SBUS*2
Power consumption Air≤25W; Ground≤10W Air≤25W；Ground≤10W
Dimension(L*W*H) 98.5mm*65.5mm*27mm 98.5mm*65.5mm*27mm
Weight 198g 198g
Working voltage DC 9 – 26V; Typical: 12V@3A DC 9 – 26V; Typical: 12V@3A
Working temperature -40~+70°C -40~+70°C
