Features
- Nationally produced, with independent control over all core components.
- Each component has independent functionswith simplified installation and fewer connections, allowing for easy replacement and upgrade.
- Equipped with AI intelligent recognition algorithms, capable of automatically identifying targets for unmanned operation.
- Three-axis gyro inertial stabilization platformensures stable and high-quality images in dynamic conditions.
- Multiple anti-corrosion processesallow reliable operation in high-salt and high-humidity environments.
- Capable of receiving external target guidancesuch as radar and AIS for coordinated operations.
Parameters
| Category | Parameter Value |
| Infrared Thermal Camera | |
| Detector type | Long-wave uncooled |
| Effective target surface | 1280 × 1024 |
| Horizontal FOV | 18.6° / 7.3° |
| Visible Light Camera | |
| Image resolution | 1920 × 1080 |
| Horizontal FOV | 1.86° ~ 51.9° |
| Laser Rangefinder | |
| Wavelength | 15Xnm |
| Frequency | 1Hz / 5Hz / 10Hz |
| Ranging distance | 150m ~ 10000m |
| Ranging accuracy | ±2m |
| Servo Performance | |
| Rotation range | Azimuth × 360° ; Pitch -10° ~ +90° |
| Max rotational angular velocity | ≥100°/s |
| Stability accuracy | ≤0.3 mrad (1σ) (7° / 0.5Hz) |
| Angle measurement accuracy | ≤1 mrad |
| Tracking accuracy | ≤0.3 mrad (1σ) |
| Memory tracking | 5s |
| Environmental Adaptability | |
| Operating temperature | -40°C ~ +60°C |
| Impact vibration | Meets Annex C.3 vibration standards of GJB150.16A |
| Protection grade | IP66 |
| Electrical Interface | |
| Power supply | AC220V, steady ≤150W, peak ≤200W |
| Communication | Gigabit network / RS422 |
| Video | Gigabit network |
| Dimension & Weight | |
| Weight | ≤12kg |
| Dimensions | Φ(240±2) mm × (330±2) mm |
Effective Range
- Visible Light
- Recognition: Personnel 3.5 km | Vehicle 12 km
- Detection: Personnel 6 km | Vehicle 15 km
- Infrared (IR)
- Recognition: Personnel 1.2 km | Vehicle 2.5 km
- Detection: Personnel 2.5 km | Vehicle 5 km
FAQs
Q1: What makes China Moneypro ME240 different from lighter gimbal systems (e.g., ME210)?
A1: China Moneypro ME240 is a 10kg-class system with a higher resolution IR detector (1280×1024), extended laser ranging distance up to 10 km, and improved stability accuracy. It is specifically built for heavy-duty, vehicle-mounted applications requiring long-duration and long-range performance.
Q2: How does the AI recognition system enhance operational efficiency?
A2: The onboard AI recognition algorithms can automatically identify, classify, and track multiple targets. This reduces operator workload, improves tracking accuracy, and enables semi- or fully unmanned operation in surveillance missions.
Q3: Can China Moneypro ME240 withstand harsh environmental conditions?
A3: Yes, China Moneypro ME240 is built with multi-layer anti-corrosion treatments, an IP66 protection grade, and wide operating temperatures from -40°C to +60°C. This ensures reliability in desert, coastal, and tropical high-humidity environments.
Q4: What kind of platforms can China Moneypro ME240 be integrated with?
A4: The system is designed for vehicle-mounted operations but can also be adapted to ships, ground stations, or other heavy platforms. Its Gigabit network / RS422 interfaces allow seamless integration with C4ISR and radar-guided systems.
Q5: What are the maintenance and upgrade benefits of the modular design?
A5: Each component of China Moneypro ME240 is designed for independent replacement and upgrade, which reduces downtime, minimizes service costs, and allows customers to update specific modules (e.g., sensors, processors) without replacing the entire system.
