Key Features
- Lightweight Design: Optical, mechanical, and electrical lightweight design reduces weight without compromising performance.
- Nationally Produced: Fully independent production and control over core components.
- AI Intelligent Recognition: Equipped with AI recognition algorithm for automatic target identification and unmanned operation.
- Stable Imagery: Three-axis gyro inertial stabilization ensures steady and clear images under dynamic conditions.
- High Adaptability: Multi-layer anti-corrosion treatment allows reliable performance in high-salt, high-humidity, and extreme environments.
- Linkage Operation: Supports integration with external systems like radar and AIS for coordinated guidance.
Technical Parameters
Infrared Thermal Camera
- Detector Type: Long-wave uncooled
- Effective Target Surface: 640 × 512
- Horizontal FOV: 4.4° ~ 22°
Visible Light Camera
- Image Resolution: 1920 × 1080
- Horizontal FOV: 1.86° ~ 51.9°
Laser Rangefinder
- Wavelength: 1550 nm
- Frequency: 1Hz / 5Hz / 10Hz
- Measuring Distance: 150 m – 8000 m
- Accuracy: ±2 m
Servo Performance
- Rotation Range: Azimuth 360°; Pitch -10° ~ +90°
- Max Rotational Angular Velocity: ≥ 100°/s
- Stability Accuracy: ≤ 0.3 mrad (1σ) (7°/0.5 Hz)
- Tracking Accuracy: ≤ 0.3 mrad (1σ)
- Memory Tracking: 5 s
System Performance
- Angle Measurement Accuracy: ≤ 1 mrad
- Operating Temperature: -40°C ~ +60°C
- Impact Vibration: Complies with Annex C.3 vibration environment of combination wheeled vehicles in GJB150.16A
Environmental Adaptability
- Protection Grade: IP66
- Impact Resistance: High vibration resistance for harsh military conditions
Electrical Interface
- Power Supply: AC220V, steady state ≤100W, peak ≤150W
- Communication: Gigabit network / RS422
- Video Transmission: Gigabit network
Dimensions and Weight
- Weight: ≤ 7 kg
- Dimensions: Φ (210 ± 2) mm × (300 ± 2) mm
Effective Range
Visible Light Camera
- Recognition Range: Personnel – 3.5 km | Vehicle – 12 km
- Detection Range: Personnel – 6 km | Vehicle – 15 km
Infrared (IR) Camera
- Recognition Range: Personnel – 1 km | Vehicle – 2 km
- Detection Range: Personnel – 2 km | Vehicle – 4 km
FAQs
Q1: What stabilization system does the China Moneypro ME210 use to ensure stable imaging during movement?
A1: China Moneypro ME210 adopts a three-axis gyro inertial stabilization platform, effectively eliminating jitter and maintaining high-quality stable imagery under vehicle vibrations or dynamic motion.
Q2: Can the China Moneypro ME210 operate in harsh environments such as coastal or desert areas?
A2: Yes, China Moneypro ME210 features multi-layer anti-corrosion and environmental protection processes, allowing reliable operation in high-salt, high-humidity, desert dust, and extreme temperature conditions (-40°C to +60°C).
Q3: What is the effective detection range of the laser rangefinder?
A3: The integrated 1550 nm eye-safe laser rangefinder measures distances from 150 m up to 8000 m with an accuracy of ±2 m, making it ideal for long-range reconnaissance and target positioning.
Q4: Is China Moneypro ME210 compatible with external battlefield systems?
A4: Yes, China Moneypro ME210 supports linkage operation with external systems such as radar and AIS, enabling coordinated target guidance and improved battlefield integration.
Q5: What are the power requirements of China Moneypro ME210?
A5: China Moneypro ME210 operates on AC220V, with steady-state consumption of ≤100W and a peak load of ≤150W, ensuring efficient power management in vehicle-mounted deployments.
