Home » Unmanned System Products » MYD-KS614/914 Backpack station -DUAL BAND
One-Stop Energy-Saving Solutions for Electric Motors
Back to products
China moneypro MOP (X27)

MYD-KS614/914 Backpack station -DUAL BAND

The MYD-KS614/914 are high-performance wireless communication modules designed for reliable, low-latency data transmission in demanding scenarios like industrial automation, unmanned system integration, and remote monitoring. Operating across distinct frequency bands—614MHz for KS614 and 914MHz for KS914—both modules feature advanced anti-interference technology, ensuring stable connectivity even in environments with signal obstructions or electromagnetic interference.
With compact, lightweight designs, they integrate easily into UAVs, sensors, or industrial controllers, while supporting flexible P2P/P2MP working modes and secure data encryption to protect critical information. Their rugged build (wide operating temperature range of -40°C~+70°C, dust/water resistance) and consistent performance make them versatile solutions for industrial, aerospace, and public safety applications.
Category: UAV Data link/Video transmission
Share:
  • Description
Description

Transmission Distance

  • 30KM+

Product Feature

  • Built-in dual-frequency module
  • Integrated backpack structure
  • Compatible with various handheld remote controls

Product Parameter

System parameter Technical index
Equipment type KS614/KS914
Working frequency KS614: 600MHz&1.4GHZ; KS914: 900MHz&1.4GHZ
Radio frequency channel 2T2R
Output power 33dBm (2W)
Channel bandwidth 10MHz/20MHz
Modulation mode QPSK; 16QAM
Maximum rate 23.9Mbps@20MHz
Communication encryption AES256
Transmission delay ≤10ms
Radio frequency interface N-type female head*2
Device interface 8pin Lemo: Ethernet*1; 6pin Lemo: TTL/RS232*1, SBUS*1
Power consumption ≤15W
Level of Protection IP53
Dimension(L*W*H) 240mm*200mm*60mm
Weight 2.5kg
Battery life 6 hours
Charging voltage 25.2V
Working temperature -20~+65°C
