Product Features
Default outputs include:
- 3-axis angular velocity
- 3-axis acceleration
- Temperature data
Applications
- Guidance and stabilization systems
- Borehole and tunnel surveying
- Vehicle and ship navigation
- UAV and autonomous driving platforms
- Industrial robotics and precision measurement
- Satellite attitude and antenna stabilization
- Oil drilling and exploration systems
- Mapping and port measurement systems
- Lidar and laser measurement systems
Performance Specifications
| Parameter | Specification |
| General | |
| Weight | 52 g |
| Measurement Range | ±400°/s |
| Resolution | 24 bits |
| Startup Time | 0.7 – 1 s |
| Sampling Rate | 125 Hz – 2000 Hz |
| Shock Resistance | 1500 g |
| Power | |
| Supply Voltage | 4.5 V – 5.5 V (typ. 5 V) |
| Power Consumption | 1.2 W (typ.) / 1.5 W (max) |
| Gyroscope Performance | |
| Bias Instability | 0.3°/h |
| Angular Random Walk | 0.15°/√h |
| Bias Temperature Sensitivity | ±10°/h rms |
| Scale Factor Nonlinearity | 500 ppm |
| Scale Factor Sensitivity | 400 ppm/g |
| Bandwidth (–3 dB) | 262 Hz |
| Data Latency | 1.6 ms |
| RS422 Bit Rate | Up to 921,600 Mbit/s |
| Environmental | |
| Operating Temperature | –40 °C ~ +85 °C |
| Storage Temperature | –50 °C ~ +90 °C |
Key Benefits
- Ultra-fast startup (≤ 1 s)for rapid deployment
- High sampling rate (up to 2000 Hz)for precision control and real-time applications
- Low bias instability (0.3°/h)for reliable navigation and stabilization
- Compact and lightweight (52 g), ideal for UAVs, robotics, and aerospace platforms
- Wide temperature range (–40 °C to +85 °C)and 1500 g shock resistance for rugged environments
- Fully ITAR-free, ensuring seamless global export and integration
Q1: What is the startup time of China Moneypro MP-IM012 MEMS gyroscope and why does it matter?
A1: China Moneypro MP-IM012 features an ultra-fast startup time of less than 1 second, making it ideal for applications where rapid deployment is critical, such as UAV navigation, autonomous driving, and emergency robotics. This allows users to reduce downtime and begin operations almost instantly.
Q2: How does China Moneypro MP-IM012 handle high-speed data acquisition?
A2: China Moneypro MP-IM012 supports an exceptionally high sampling rate up to 2000 Hz, ensuring precise and real-time motion tracking. Combined with a low data latency of just 1.6 ms, it provides reliable performance for stabilized platforms, industrial robotics, and advanced geospatial mapping systems.
Q3: Why is China Moneypro MP-IM012 suitable for harsh industrial and defense environments?
A3: With an operating temperature range of –40 °C to +85 °C, shock resistance of 1500 g, and compact weight of just 52 g, China Moneypro MP-IM012 delivers stable operation even in extreme industrial, aerospace, and defense conditions. Its rugged design ensures long-term stability and resilience.
Q4: Is China Moneypro MP-IM012 restricted by ITAR regulations for international use?
A4: No. China Moneypro MP-IM012 MEMS gyroscope is ITAR-free, making it easier for international customers to integrate and deploy across multiple industries without export restrictions. This makes it an attractive choice for global UAV manufacturers, robotics companies, and navigation solution providers.
Q5: What are the key performance advantages of China Moneypro MP-IM012 compared to other MEMS gyroscopes?
A5: China Moneypro MP-IM012 combines low bias instability (0.3°/h) with angular random walk of 0.15°/√h, delivering high navigation accuracy. Unlike many MEMS gyros, it achieves this while maintaining low power consumption (1.2–1.5 W) and a wide dynamic range (±400°/s), making it a top-tier choice for precision navigation and control applications.
