Introduction: Revolutionizing Mobile Network Positioning with the MOP TECH Full-Band Detection System
n
The MOP TECH full-band 2G/3G/4G/5G portable high-precision positioning detection system sets a new industry benchmark as the first multi-standard, portable integrated design. This cutting-edge system supports all major cellular standards from 2G to 5G, allowing it to adapt seamlessly to complex network environments. Whether in dense urban villages or high-rise areas, its performance remains exceptional, providing reliable detection and positioning where other systems struggle.
n
Comprising a portable host and an operating mobile phone, the system offers high maturity, superior performance, and effortless operation, making it ideal for real-world deployment. Its powerful functionality enables direct and accurate detection across all modes, while the built-in high-gain antenna ensures long positioning distances, high accuracy, and strong anti-interference capabilities. The system can simultaneously locate single or multiple targets, leveraging the base station communication infrastructure for high sensitivity, with an uplink capture rate of at least 95%. It supports six carrier channels and six concurrent and rotating frequency points, with adjustable power ranging from 2W to 6W, and an adsorption distance of 50 to 400 meters. Comprehensive management features include black and white list management, user management, and black box recording for detailed audits.
n
The system’s performance is further enhanced by its support for multiple standards from 2G to 5G, numerous frequency bands, and high sensitivity. Functional parameters are outstanding, including user capacity of at least 2,000 per carrier, a capture rate of 1,000 per minute, and a bid-winning rate of at least 98%. Powered by a 28V battery with a life span of over 3 hours, the compact device measures just 31x25x11 cm and weighs about 6 kg. It pairs with a Huawei smart control phone to deliver a convenient, efficient positioning experience that professionals can trust.
n
Comprehensive Technical Specifications
n
The following table details the full range of specifications for the MOP TECH portable high-precision positioning detection system, covering system characterization, functionality, and configuration.
n
| Category | Parameter | Specification / Value |
|---|---|---|
| System Characterization | Operating System Standards | 2G (900 & 1800), 3G (2100), 4G-LTE, 5G NR (SA+NSA) |
| Supported Frequency Bands | 2G: 900 & 1800; 3G: 2100; 4G: B1, B3, B5, B8, B34, B38, B39, B40, B41; 5G: n1, n3, n5, n8, n28, n41, n77, n78, n79 | |
| Level of Sensitivity | ≥ -105 dBm | |
| Functionality Characterization | Carrier Channels | Supports 6 carriers (4G + 5G: TDD + FDD) |
| Number of Plots | 6 subdivisions | |
| Built-in Direction Finding | 698 MHz ~ 5000 MHz, gain: 8 dBm | |
| Firing Power per Carrier | 0W ~ 6W (adjustable) | |
| Adsorption Range | 50 m ~ 300 m (non-arbitrary environment) | |
| User Capacity per Carrier | ≥ 2000 | |
| Capture Rate | ≥ 1000/minute | |
| Performance Metrics | Location Marking | IMSI code, TMSI code |
| Capture Method | Induced capture | |
| Successful Bidder Rate | ≥ 98% | |
| Non-target Release Time | ≤ 1 second | |
| Pointing Accuracy | 15 degrees | |
| Localization and Direction Finding (GPS) | Simultaneous detection and localization of single or multiple targets | |
| Management Features | Blacklists | Support single or multiple blacklists for simultaneous location |
| Whitelist Management | Unlimited, supports batch import, no interference to whitelist user network | |
| Auto Sweep | Supports automatic frequency sweeping in public network and automatic frequency point configuration | |
| Frequency Offset Synchronization | Supports automatic frequency offset synchronization in public network | |
| Advanced Capabilities | PCI Modification | Supports millisecond modification of single or multiple cell PCIs without shutting down the amplifier |
| Synchronization | GPS synchronization, air interface synchronization mode | |
| Reporting Frequency | 1 second per report | |
| Operational Details | Hybrid Network Positioning | Supports mobile, Unicom, telecom, and radio/television target mixed network detection, localization, and direction measurement |
| Operation APP | Supports any Android 12.0 or above or Harmony system smartphone | |
| Reporting Frequency | 1 sec/times | |
| Electronic Characterization | Power Supply | 28V battery powered |
| Power Consumption | ≤ 120W (depending on number of amplifiers active) | |
| Size | 31 x 25 x 11 cm | |
| Weight | 6 kg (approximately) | |
| System Configuration | Portable Mainframe | 2G/3G/4G/5G Integrated Active Portable Mainframe |
| Battery | 28V-6AH power supply, duration ≥ 3 hours | |
| Operating Terminal | Huawei Smart Control Phone |
n
Practical Applications and Performance Insights
n
The MOP TECH portable high-precision positioning detection system excels in scenarios requiring rapid, field-deployable tracking. Its ability to handle 2G/3G/4G/5G full frequency bands makes it versatile across diverse network topologies, from legacy 2G towers to cutting-edge 5G small cells. The system’s high sensitivity and up to 5G capture rate ensure operators can pinpoint targets efficiently, even in interference-rich urban environments. The built-in direction-finding antenna, covering 698 MHz to 5000 MHz, provides robust performance, while adjustable firing power (0-6W per carrier) allows operators to fine-tune for range vs. stealth.
n
For operational convenience, the system includes automated features like frequency auto-sweep and PCI modification, which can be executed in milliseconds without disabling the amplifier. This is crucial for dynamic situations requiring quick reconfiguration. The battery life of at least 3 hours supports extended missions, and the lightweight, compact design (6 kg, 31x25x11 cm) ensures easy transport and setup by a single user.
n
Detection and Targeting Effectiveness
n
The system’s effectiveness is validated by its high capture and success rates. With a capture rate of at least 1,000 per minute and a bid-winning rate of 98%, operators experience near-instantaneous target acquisition. Non-target release occurs within one second, minimizing collateral impact on routine subscribers. The pointing accuracy of 15 degrees provides reliable directional guidance, while the option for simultaneous single or multi-target tracking enhances strategic flexibility.
n
Network Compatibility and Management
n
Support for hybrid network positioning ensures that targets on any carrier—mobile, Unicom, telecom, or radio/television—can be detected and tracked simultaneously. The blacklist and whitelist management features streamline operations by allowing batch import of subscribers, ensuring that whitelisted users experience no service interference. The system’s ability to synchronize via GPS or air interface adds another layer of flexibility, ensuring accurate data across disparate network environments.
n
Advanced Features for Modern Operations
n
The MOP TECH system incorporates several advanced capabilities that distinguish it from standard positioning tools. The ability to modify PCIs on single or multiple cells without shutting down the amplifier is a significant operational advantage, enabling continuous monitoring during reconfiguration. The automatic frequency sweep and offset synchronization simplify setup in unfamiliar networks, reducing training overhead for field teams.
n
Reporting at 1-second intervals provides real-time situational awareness, while the operation APP compatibility with Android 12.0 or above and Harmony systems ensures that virtually any modern smartphone can serve as the control interface. This user-centric approach minimizes additional hardware costs and allows teams to leverage their existing devices.
n
Conclusion: Advanced Detection at Your Fingertips
n
The MOP TECH full-band portable high-precision positioning detection system redefines what is possible in mobile network-based target location. By combining multi-standard support, high sensitivity, robust automation, and a lightweight portable design, it delivers a powerful tool for law enforcement, security teams, and network operators. With features like automatic frequency sweeps, PCI modification, and hybrid network detection, it adapts to even the most challenging operational environments. Whether tracking single or multiple targets across 2G, 3G, 4G, or 5G networks, this system ensures reliable, accurate, and efficient results. The user-friendly interface, long battery life, and comprehensive management functions make it a top choice for professionals who demand precision and portability in one package. For high-stakes applications where every second counts, the MOP TECH system stands out as a trusted solution for portable high-precision positioning detection.
