400-760MHz Broadband Power Amplifier: Industrial Grade Excellence for Critical Signal Transmission
nnIn the demanding world of signal transmission and amplification, the need for robust, reliable, and high-performance solutions has never been greater. Our new 400–760MHz Broadband Power Amplifier 100W Broadband RF Power Amplifier Module is engineered to meet these challenges head-on, delivering industrial-grade performance across a wide range of applications. Whether you’re powering communication networks or driving scientific research, this module offers the stability and strength your systems require.nn
Unmatched Power and Versatility
nnThis Broadband Power Amplifier boasts an impressive 100W power output, providing ample energy to ensure signals remain strong and stable over long distances. The 400–760MHz operating frequency range enables broad coverage, making it adaptable to diverse communication scenarios, from industrial automation to advanced scientific instrumentation. The module’s high gain and low in-band flatness guarantee consistent performance, allowing you to rely on it for critical tasks where precision matters.nn
Industrial-Grade Durability
nnDesigned for the toughest environments, this amplifier meets industrial-grade standards. It operates reliably in temperatures from -10 to +55°C and withstands humidity levels of 5% to 95% (non-condensing). This resilience ensures uninterrupted operation in harsh conditions, whether in factory floors or outdoor installations. The housing is compact yet robust, measuring 130 by 117 by 26 mm, making it easy to integrate into existing systems without compromising on performance.nn
Technical Specifications at a Glance
nnThe following table details the key parameters of the Broadband Power Amplifier, ensuring you have all the data needed for seamless integration.nn
| Parameter | Value (400-480MHz) | Value (500-760MHz) |
|---|---|---|
| Saturated Power Output | 50±1dBm | 47±1dBm |
| Gain | 50±2dB | 47±2dB |
| In-Band Flatness | ≤2dB | ≤3dB |
| Working Current | ≤8A | ≤7A |
| Input and Output VSWR | ≤1.5 | ≤1.5 |
| Out-of-Band Spurs | 9kHz–1GHz: ≤-36dBm/30kHz; 1GHz–12.75GHz: ≤-30dBm/30kHz | |
| Maximum Lossless Input | +10dBm | |
| Operating Voltage | DC+28V | |
| Power Supply Interface | 7W2 | |
| RF Ports | RFIN: SMA-KFD; RFOUT: N-F | |
| Monitoring Interface | 7W2 | |
| Amplifier Size | 130 x 117 x 26mm | |
| Operating Temperature | -10 to +55°C | |
| Relative Humidity | 5% to 95%, non-condensing | |
| Storage Temperature | -25 to +65°C | |
nn
Seamless Connectivity and Integration
nnThe Broadband Power Amplifier features a user-friendly interface design. The input uses an SMA-KFD connector, while the output employs an N-F connector, ensuring fast and stable connections that integrate effortlessly with existing equipment. The 7W2 power supply and monitoring interfaces simplify installation and enable real-time performance tracking, reducing downtime and boosting efficiency.nn
Ideal for Diverse Applications
nnThis module excels in multiple environments, from industrial automation control to intelligent communication systems. It is particularly valuable for building industrial communication networks and supporting scientific research and testing scenarios. By choosing this Broadband Power Amplifier, you invest in advanced technology that guarantees reliable signal amplification, ensuring your operations run smoothly.nn
Conclusion
nnIn summary, the 400–760MHz Broadband Power Amplifier 100W Broadband RF Power Amplifier Module stands out as an industrial-grade solution for those who demand excellence. Its exceptional power output, wide frequency range, and robust construction make it a reliable partner for any signal amplification need. With a focus on quality and performance, this Broadband Power Amplifier is the key to unlocking superior communication and testing outcomes. Choose it to secure the promise of advanced technology and unwavering performance.
