China Moneypro 16km Drone Transmitter Receiver With 800Mhz And 1.4Ghz For Video And Data

Introducing the FPM-8416 Drone Video Transmitter Designed for commercial and industrial drones, the FPM-8416 is a lightweight video transmitter with an embedded bi-directional data link, enabling fully autonomous operations. It provides wireless control and real-time video monitoring of your UAV from up to 10 miles away. Built around a 4th-generation COFDM multi-carrier modulation core, this system delivers exceptional performance and robust security—even in the most challenging environments.

Category:
Description




Key Features

Superior Video Performance

  • Crystal-clear 1080P/60 video at ranges up to 14–16km
  • Ultra-low 80ms latency for real-time responsiveness
  • HDMI + IP video input/output support

Advanced Transmission Technology

  • 800MHz & 1.4GHz frequency options to avoid crowded 2.4GHz bands
  • 128-bit AES encryption for secure data transmission

Designed for Drones

  • Lightweight 130g construction
  • CNC-machined aluminum actuator case for durability

User-Friendly Control

  • Bi-directional control capability
  • Fully customizable via intuitive software
  • Real-time monitoring with HDMI output display

Ready to elevate your drone operations with professional-grade video downlink?



long range drone video transmitter



Powerful Long-Range Communication The FPM-8416 datalink delivers full HD video and two-way control data up to 10 miles. Using COFDM demodulation technology, it ensures a strong non-line-of-sight (NLOS) connection with high fade margin for reliable performance. Secure & Versatile Operation This wireless system features built-in AES-128 encryption (CBC) to protect your data. For added flexibility, encryption can be bypassed to operate in unencrypted mode when needed. Built for Tough Environments With FHSS (Frequency-Hopping Spread Spectrum) anti-jamming technology, the FPM-8416 maintains a stable link even in challenging conditions. Advanced algorithms further enhance performance in complex operational scenarios. Flexible Connectivity Equipped with HDMI, two LAN ports, and a bi-directional serial port, the FPM-8416 lets you stream full HD video while simultaneously controlling your flight via Pixhawk. The HDMI and LAN options also support a wider variety of camera types for your drone.

FPM-8416 Best Drone Transmitter






Weighing just 130 grams, this compact UAV video link is designed for small drones without sacrificing performance. Trusted in mission-critical fields, it delivers clear, real-time video in the most demanding situations.

Key applications include:

  • Public Safety & Emergency Response – Police, fire, and first responder operations
  • Infrastructure & Inspection – Monitoring oil pipelines, high-voltage power lines, and structural assets
  • Environmental Protection – Early detection and prevention of threats like forest fires
  • Security & Surveillance – Border control, traffic management, and homeland security
  • Defense & Technical Units – Specialized military and support operations
  • Aviation & Crisis Response – Airport operations and major incident coordination

Built for reliability when every second counts.





16km Drone Video Transmitter



Specifications
Frequency 800Mhz 806~826 MHz
1.4Ghz 1428~1448 MHz
Bandwidth 8MHz
RF Power 0.6watt(Bi-Amp, 0.6watt Peak Power of each power amplifier)
Transmit Range 800Mhz: 16km1400Mhz: 14km
Antenna 800Mhz TX:Omni Antenna/25cm Length/ 2dbiRX:Omni Antenna/60cm Length/6dbi
1.4Ghz TX:Omni Antenna/35cm Length/3.5dbiRX:Omni Antenna/60cm Length/5dbi
Transmit Rate 3Mbps (HDMI Video Stream, Ethernet Signal and serial data share)
Baud Rate 115200bps(Adjustable)
Sensitivity -106@4Mhz
Wireless Fault Tolerance Algorithm Wireless baseband FEC forward error correction/ video codec super error correction
End to End Latency Latency for encoding + transmission + decoding
720P/60
1080P/60
Link Rebuild Time
Modulation Uplink QPSK/Downlink QPSK
Video Compression H.264
Video Color Space 4:2:0 (Option 4:2:2)
Encryption AES128
Start Time 15s
Power DC12V (7～18V)
Interface Interfaces on Tx and Rx are same
Video input/Output: Mini HDMI×1
Power Input Interface×1
Antenna Interface:SMA×2
Serial×1: (Voltage:+-13V(RS232), 0~3.3V(TTL)²
Ethernet: 100Mbps x 3
Indicators Power
Wireless Connection Setup Indicator
Power Consumption Tx: 9W(Max)Rx: 6W
Temperature Working: -40 ~+ 85℃Storage: -55 ~+100℃
Dimension Tx/Rx: 93 x 55.5 x 23.5 mm
Weight Tx/Rx: 130g
Metal Case Design CNC technology/ double aluminum alloy shell
Double Aluminum Alloy Shell
Conductive anodizing craft
