Ultimate Protection: The High-Power Multi-Frequency Jammer for Demanding Environments
nn
In an era where wireless communication and unmanned aerial vehicles pose significant security risks, the need for robust, reliable countermeasures has never been greater. Enter the professional high-power mobile phone jammer, a formidable solution designed for outdoor waterproof projects. This device is not merely a signal disruptor; it is a comprehensive security system engineered to block a wide spectrum of cellular frequencies, including GSM, CDMA, 3G, 4G, and 5G networks. Furthermore, it can be customized to disrupt Wi-Fi, UHF, and VHF signals, making it one of the most versatile jammers on the current market.
nn
More than a cellular jammer, this unit functions as a high-power RF drone jammer, capable of defending against 100% of UAV threats, including popular models like the Phantom 4 and Phantom 3 series. With its robust construction featuring 6 to 8 antennas and 4 cooling fans, it delivers relentless jamming power for 24/7 continuous operation. Whether you are protecting a sensitive government facility or managing a large public event, this jammer offers the strength and adaptability required to maintain absolute signal control.
nn
Critical Applications and Use Cases
nn
This high-power jammer is not a consumer gadget; it is a professional tool for mission-critical environments. Its applications are diverse and essential for security, law enforcement, and national infrastructure protection.
nn
- n
- Protection of Prohibited Areas: Safeguard prisons, management zones, national strategic resource projects, nuclear industry facilities, airports, and political regions from unauthorized communication and drone intrusions.
- Prevention of Information Leakage: Secure on-site operations such as major criminal investigations, urban management law enforcement, important security venues, political figure protection, large-scale performance rehearsals, archaeological excavations, and large group events.
- Countering Illegal Drone Activities: Combat the use of UAVs for transport, drug trafficking, smuggling of illegal goods, or unauthorized information transmission.
n
n
n
nn
High-Power Drone Jammer: Technical Specifications at a Glance
nn
Understanding the technical capabilities of this high-power drone jammer is crucial for selecting the right model for your specific needs. Below is a comprehensive breakdown of its operating parameters and physical characteristics.
nn
Frequency and Output Power Specifications
nn
| Channel | Frequency Band | Frequency Range | Average Output Power |
|---|---|---|---|
| 1 | CDMA / GSM | 851-960 MHz | 47 dBm / 50W |
| 2 | 4G 2600 | 2500-2690 MHz | 47 dBm / 50W |
| 3 | 5G 3500/3700 | 3400-3800 MHz | 47 dBm / 50W |
| 4 | WiFi 2.4G / 4G 2300 | 2300-2500 MHz | 47 dBm / 50W |
| 5 | 3G | 2110-2170 MHz | 47 dBm / 50W |
nn
Physical and Power Specifications
nn
| Parameter | Value |
|---|---|
| Power Supply | AC Adapter 50-60Hz (AC 110V or 240V to DC 27V) |
| Dimensions (W x H x L) | 510 x 450 x 240 mm |
| Package Size | 65 x 55 x 35 cm |
| Net Weight | 29 kg |
| Gross Weight (without antennas) | 35 kg |
| Total Power Consumption | 300W |
| Shielding Radius | 20-200 meters (depends on signal strength) |
| Warranty | One year from delivery date |
nn
Antenna Specifications
nn
| Antenna Type | Dimensions (L x W x H) | Net Weight | Gain | VSWR | Beamwidth |
|---|---|---|---|---|---|
| Omni Directional | 900 x 35 mm | 1 kg | 5-10 dBi | 1.5 | H: 360° |
| Directional (Basic Station) | 125 x 25 x 8.5 cm | 10 kg | 12-20 dBi | 1.5 | H: 60-90° / V: 20-30° |
nn
Key Advantages of the High-Power Drone Jammer System
nn
This advanced jammer is built for performance and endurance. Its total output power of 200-300W, combined with high-gain omni or directional antennas, ensures a shielding radius of 20 to 200 meters, depending on the ambient signal strength. Each unit can jam up to 6 or 8 frequency bands simultaneously, with each band being independently controlled and power-adjustable from maximum to zero. Safety is paramount, featuring 100% safe VSWR over-protection (isolator) for each module. The large aluminum alloy shell and multiple cooling fans allow for non-stop operation, while the IP65 design ensures outdoor installation is secure and weather-resistant. Additionally, the build includes safeguards against sabotage.
nn
In conclusion, whether you require a high-power drone jammer for perimeter defense or a cellular jammer for information security, this system delivers unmatched performance. Its robust technical parameters, versatile application range, and durable construction make it an indispensable asset for any professional security operation. Invest in the ultimate signal control solution and ensure your environment remains protected around the clock.
