Key Features
- Dual FOV Switchingfor rapid transition between wide and narrow fields of view.
- Equipped with 3rd-gen 12μm/640×512 (50Hz) infrared detectorfor high-resolution imagery.
- Detects and identifies single-person targets at distances up to 800 meters.
- 24/7 operationwith hot-swappable battery replacement capability.
- Rugged magnesium alloy shellwith IP67 protection rating, suitable for harsh environments.
- Withstands 1200g/0.3ms shocks, adaptable to jungles, plateaus, deserts, and cold regions.
- Intuitive single-scrollwheel designfor effortless operation.
- Directional guidance indicators with photo/video capture(stores 10,000 images or 12 hours of video).
- Wi-Fi enabledfor image transmission and remote command control.
- Intelligent reticle adjustment to maximize first-round hit probability.
- Supports multi-range and mil-dot reticlesfor precise shooting.
- Adaptable to multiple weapon platformsfor tactical flexibility.
- Automatic target recognitionto enhance combat efficiency.
- Modular designfor rapid deployment.
Technical Parameters
IR Parameters
- Resolution: 640×512
- Pixel Pitch: 12μm
- Frame Rate: 50Hz
- OLED Display: 1024×768
Power Supply
- Battery: External 1×18650 / Internal 2×18500
- Operating Time: 12 hours
Physical Characteristics
- Weight: ≤860g
- Dimensions: ≤275mm × 95mm × 95mm
Environmental Requirements
- Protection: IP67
- Operating Temperature: -40℃ ~ +55℃
- Reliability: 1200g/0.3ms
Interface
- Electrical: Type-C / RS232 / PAL
- Mechanical: Standard Picatinny Rail
Laser Module (Optional)
- Wavelength: 905nm
- Measurement Range: 50–2000m
- Accuracy: ±2m
Optical Parameters
- Focal Length (WFOV): 25mm
- WFOV: 17.5° × 14.3°
- Focal Length (NFOV): 50mm
- NFOV: 8.8° × 7.2°
- Diopter Adjustment: -4D ~ +2D
- Exit Pupil Distance: ≥35mm
Functional Parameters
- Display Modes: White Hot, Black Hot, Red Hot, Green Hot, Lava, Rainbow, Outline
- Digital Zoom: 1–4×
- Digital Compass: Azimuth, Pitch, Roll angle
- Memory: 128GB
- Intelligent Target Recognition: Personnel, Vehicles, Drones
- Reticle: Multi-range and Mil-dot Reticles
- Custom Reticle: Supports offline customization and upgrade
- Picture-in-Picture: Yes
- Probabilistic Ranging: Yes
- One-Click Zeroing: Yes
- Ballistic Calculation: Yes
- Wi-Fi: Yes
Effective Range
- IR Recognition: Personnel 0.8 km | Vehicle 1.6 km
- IR Detection: Personnel 2 km | Vehicle 4 km
FAQ:
Q1: How does the dual-FOV system improve tactical performance?
A1: The dual-FOV design allows users to seamlessly switch between wide-angle situational awareness and narrow-angle precision aiming, ensuring maximum flexibility in both close-quarter and long-range scenarios.
Q2: What makes the China Moneypro MPS650 suitable for extreme environments?
A2: With its IP67-rated magnesium alloy shell and ability to withstand 1200g/0.3ms shocks, the MPS650 performs reliably in deserts, jungles, plateaus, and arctic conditions.
Q3: Can the China Moneypro MPS650 support real-time data sharing?
A3: Yes, the integrated Wi-Fi transmission system enables real-time image transfer and remote command control, critical for team coordination and tactical operations.
Q4: What is the effective detection and recognition range?
A4: The China Moneypro MPS650 provides personnel recognition up to 800m and vehicle recognition up to 1.6 km, with extended detection ranges of 2 km for personnel and 4 km for vehicles.
Q5: Is the reticle system customizable?
A5: Yes, China Moneypro MPS650 supports multi-range and mil-dot reticles, as well as offline reticle customization and upgrades, ensuring adaptability to specific mission requirements.
